SWP-0412G2 Series L2 Web Smart Switch User Guide Homepage After successful log-in, the “SYSTEM Configuration” page appears (this is also the

SWP-0412G2 Series L2 Web Smart Switch User Guide System The System window provides the Switch’s system information and allows users to config

SWP-0412G2 Series L2 Web Smart Switch User Guide Note: After applying a new IP address, a new log-in page will appear automatically. Please l

SWP-0412G2 Series L2 Web Smart Switch User Guide Max Frame length Adjust the size of Jumbo Frames. The default is 1518 bytes. The Maximum val

SWP-0412G2 Series L2 Web Smart Switch User Guide VLAN VLAN divides the network members into groups to reduce packet collisions and improve th

SWP-0412G2 Series L2 Web Smart Switch User Guide PVID When the VLAN-enabled Switch receives a tagged packet, the packet will be sent to the p

SWP-0412G2 Series L2 Web Smart Switch User Guide Aggregation/ Trunk Configuration To set up the port trunk groups, put the selected ports’ nu

SWP-0412G2 Series L2 Web Smart Switch User Guide Quality of Service QoS enhances communication quality by giving precedence to certain classe

SWP-0412G2 Series L2 Web Smart Switch User Guide Port-based mode QoS: Port-based QoS allows users to configure each port as having a high o

SWP-0412G2 Series L2 Web Smart Switch User Guide Tag-based QoS: Tag-based QoS assigns packet priority according to the tags on the packets.

SWP-0412G2 Series L2 Web Smart Switch User Guide Table of Contents UNPACKING INFORMATION ... 4 INTRODUCTION

SWP-0412G2 Series L2 Web Smart Switch User Guide DSCP-mode QoS: DSCP-mode QoS assigns packet priority according to the types of the incomin

SWP-0412G2 Series L2 Web Smart Switch User Guide Mirror The Mirror function copies all the packets that are transmitted by the source port to

SWP-0412G2 Series L2 Web Smart Switch User Guide Rate Limit The “Rate Limit” page allows users to limit the bandwidth for each port and confi

SWP-0412G2 Series L2 Web Smart Switch User Guide SNMP This device supports SNMP-management, which allows network administrators to monitor an

SWP-0412G2 Series L2 Web Smart Switch User Guide Discovery After installing a series of our switches, the discovery management tool helps use

SWP-0412G2 Series L2 Web Smart Switch User Guide Statistics Overview The Statistics Overview is provided for users to see the general trans

SWP-0412G2 Series L2 Web Smart Switch User Guide Restart Restart: To restart the system, click the “Yes” button. The system restarts and sh

SWP-0412G2 Series L2 Web Smart Switch User Guide Software Upload This “Software Upload” page allows users to upgrade firmware for this Switch

SWP-0412G2 Series L2 Web Smart Switch User Guide Appendix- Command Line Interface Start-up and Terminal configuration To start the Command Li

SWP-0412G2 Series L2 Web Smart Switch User Guide Command Hierarchy After logging in, press ? + <enter> to show the 9 command groups. S

SWP-0412G2 Series L2 Web Smart Switch User Guide STATISTICS OVERVIEW ...

SWP-0412G2 Series L2 Web Smart Switch User Guide Command Description These are the group commands of the command line interface: Command gro

SWP-0412G2 Series L2 Web Smart Switch User Guide [<name>]: String of up to 16 characters (default: Show system name). System Reboot Des

SWP-0412G2 Series L2 Web Smart Switch User Guide Port Commands Commands at Port level: Port Configuration [<portlist>] Port Mode [<p

SWP-0412G2 Series L2 Web Smart Switch User Guide Port Admin [<portlist>] [enable|disable] Description: Set or show the admin state for

SWP-0412G2 Series L2 Web Smart Switch User Guide VLAN Commands Commands at VLAN level: VLAN Configuration [<portlist>] VLAN Add <vid

SWP-0412G2 Series L2 Web Smart Switch User Guide VLAN Egress [<portlist>] [untagged|tagged] Description: Set or show the VLAN egress mo

SWP-0412G2 Series L2 Web Smart Switch User Guide Aggregation Commands Commands at Aggr level: Aggr Configuration Aggr Add <portlist> Ag

SWP-0412G2 Series L2 Web Smart Switch User Guide QoS Commands Commands at QoS level: QoS Configuration [<portlist>] QoS Mode [<po

SWP-0412G2 Series L2 Web Smart Switch User Guide QoS DiffServ [<dscpno>] [<class>] Description: Set or show the IP Differentiated

SWP-0412G2 Series L2 Web Smart Switch User Guide IP Commands Commands at IP level: IP Configuration IP Setup [<ipaddress> [<ipmask

SWP-0412G2 Series L2 Web Smart Switch User Guide Unpacking Information Congratulations on purchasing this 16-port Gigabit Web Smart Switch wit

SWP-0412G2 Series L2 Web Smart Switch User Guide Ratelimit Commands Commands at Ratelimit level: Ratelimit Configuration Ratelimit Setup <

SWP-0412G2 Series L2 Web Smart Switch User Guide Ratelimit Egress [<portlist>] [enable|disable] [<rate>] Description: Set or sh

SWP-0412G2 Series L2 Web Smart Switch User Guide Product Specifications Standard IEEE802.3 10BASE-T IEEE802.3u 100BASE-TX IEEE802.3x full-dupl

SWP-0412G2 Series L2 Web Smart Switch User Guide The Front Panel The front panel features all the LED indicators and ports: Device LED: LE

SWP-0412G2 Series L2 Web Smart Switch User Guide Port Operation The auto-negotiation feature allows ports to run at one of the following ope

SWP-0412G2 Series L2 Web Smart Switch User Guide Installation This Switch can be placed on your desktop or mounted in a rack. Installation is

SWP-0412G2 Series L2 Web Smart Switch User Guide Description of Switch Functions Jumbo Frame The Switch supports Jumbo Frames, which means th

SWP-0412G2 Series L2 Web Smart Switch User Guide Management guide Access the Switch This section shows you how to access and use the Switch’
